COMMERCIAL CONCRETE MIXING STATION

Concrete mixing plant 180-500 m3/h

Commercial concrete mixing plant: researched, designed and manufactured by AHS according to ISO 9001:2015 standards and evaluated and certified by NQA.

Pre-sales service
Free consultation for customers to choose a concrete mixing plant configuration suitable for production specialties, premises, finances...
Welcoming customers to visit the factory, introducing or taking customers to visit some AHS mixing plants in Hanoi and neighboring provinces.
Techniques to develop a mixing plant layout plan at the mixing plant construction project site for customer approval.

Concrete Batching Plant Details :

Rated Capacity (m³/h) 180

Discharge Gate

 Manufacturer SICOMA
Symbol MAO6000/4000
DC capacity 02×75 Kw
Exhaust door Đóng mở bằng thủy lực
Cement silo (Ton) – Optional: 01÷08 silos per plant
– Capacity: 40÷200 tons per silo
Hopper containing aggregates – Optional: 02÷06 aggregate components
– Capacity: 18 m³ per compartment
– Discharge gates: 02 gates per compartment, Bottom cone: Hot-dip galvanized
Aggregate feeding form to mixer bowl – Rubber belt conveyor
+ HGT hollow-shaft motor (direct drive to conveyor drum)
Cement screw conveyor D273 –  Productivity: 80 Tons/hour
Dosing system

Aggregates (Independent weighing)/per compartment
(Accuracy: Static weighing ≤ 0.5%; Dynamic batching ≤ 1.0%)

 – Largest scale: 5500kg (with stone)
– Smallgest scale: 550kg

Cement
(Accuracy: Static weighing ≤ 0.5%; Dynamic batching ≤ 1.0%)

 – Largest scale: 2400kg
– Smallgest scale: 240kg

Fly Ash
(Accuracy: Static weighing ≤ 0.5%; Dynamic batching ≤ 1.0%)

 – CLargest scale: 1000kg
– Smallgest scale: 100kg
Water
(Accuracy: Static weighing ≤ 0.5%; Dynamic batching ≤ 1.0%)		 – Largest scale: 1000kg
– Smallgest scale: 100kg
Liquid Admixture
(Accuracy: Static weighing ≤ 0.5%; Dynamic batching ≤ 1.0%)		 – Largest scale: 70kg
Central dust filtration system

– PLC S7 – 1200 SIEMEN
– Working mode:

+ Fully automatic

+ Automatically weigh ingredients

+ Manual control
Central dust filtration system Designed and manufactured specifically for concrete mixing plants
Working voltage (V) 380V – 50H (440V – 60Hz)
Power consumption (Kw) 290
