COMMERCIAL CONCRETE MIXING STATION
Concrete mixing plant 120-150 m3/h
Commercial concrete mixing plant: researched, designed, manufactured by AHS according to ISO 9001:2015 standards, evaluated and certified by NQA.
Pre-sales service
Free consultation for customers to choose a concrete mixing plant configuration suitable to production characteristics, premises, finance...
Welcoming customers to visit the factory, introducing or taking customers to visit some of AHS's mixing plants in Hanoi and neighboring provinces.
Appoint a technician to develop a layout plan for the installation of the mixing plant at the construction site where the mixing plant is expected to be installed for the customer's approval.
Details of concrete mixing plant:
Rated productivity (M3/H)
| Rated productivity (M3/H) | 120÷150 | |
|
Mixer with two horizontal shafts |
Manufacturer |
CALET |
|
Symbol |
MAO 3750/2500 (MAO4500/3000) | |
| DC capacity | 02×45 Kw (02x55Kw) | |
| Exhaust door |
Opens and closes hydraulically | |
| Cement silo (Ton) |
– Options: 01 ÷ 08 Silo/ 1 station – Capacity: 40 ÷ 200 Ton/Silo |
|
| Hopper containing aggregates |
– Optional: 02÷06 aggregate components – Capacity 18m3/compartment – Discharge door: 02 doors/chamber, hot-dip galvanized bottom cone |
|
| Aggregate feeding form to mixer bowl |
– Rubber conveyor belt. + Negative shaft HGT motor (direct drive to drum) |
|
| Cement screw conveyor | D273 – Productivity: 80 Tons/hour | |
| Dosing system | Cốt liệu (Cân dộc lập)/ 1 khoang (Cấp sai số: Cân tĩnh≤0.5%; Cân định lượng≤1.0%) |
– Largest scale: 3500kg (với đá) – Smallgest scale: 350kg |
| Xi măng (Cấp sai số: Cân tĩnh≤0.5%; Cân định lượng≤1.0%) |
– Largest scale: 2400kg – Smallgest scale: 240kg |
|
| Nước (Cấp sai số: Cân tĩnh≤0.5%; Cân định lượng≤1.0%) |
– Largest scale: 1000kg – Smallgest scale: 100kg |
|
| Phụ gia lỏng (Cấp sai số: Cân tĩnh≤0.5%; Cân định lượng≤1.0%) |
– Largest scale: 70kg | |
|
– PLC S7 – 1200 SIEMEN + Fully automatic + Automatically weigh ingredients + Manual control |
||
| Central dust filtration system | Designed and manufactured specifically for concrete mixing plants | |
| Working voltage (V) | 380V – 50H (440V – 60Hz) | |
| Power consumption (Kw) | 185÷205 | |
